IP-LOGIC ESSENTIALS

Control Processor

The Essentials unit is the control server for all IP-Logic AVoIP devices.  This small form-factor powerhouse provides full management and diagnostics of all IP-Logic devices on the network.  The integrated Web-based GUI offers intuitive drag-and-drop graphical icons to quickly configure an AVoIP deployment.  With appropriate drivers, 3rd party control systems can interface with Essentials for easy integration with customized AV automation systems.

Essentials features two LAN ports to isolate the dedicated IP-Logic AVoIP network with the facility network.  The facility network is used to control IP-Logic devices and typically hosts the 3rd party control systems and/or Web browser-based devices such as computers and tablets.  When provided with Internet access through the facility network, Essentials can automatically download the latest firmware to keep your IP-Logic devices up to date.

  • Web-based graphical user interface
  • Isolates Video distribution network from house network
  • Works with entire IP-Logic platform
  • Provides SFP for long halls

General
ESD Protection Human body model: ±8kV (air-gap discharge), ±4kV (contact discharge)
USB 1x USB 3.0 (Reserved for future use)
Processor Marvell Armada A388 ARM A9 Dual Core 1.6GHz
Memory 1GB RAM, 8GB eMMC
SDVOE LAN Port 1x 1G RJ-45 (IP-Logic Domain), 1x 1G SFP+ Optical (AVoIP Ethernet Domain)
Control LAN Port 1x 1G RJ-45 (Facility Ethernet Domain)
Dimension 103mm x 75mm x 30mm
Temperature 0° to 40° C (10% - 90% Non-Condensing Humidity)
Power 12-VDC, 1A
Regulatory Safety and Emissions CE, FCC, RoHS
Key Features

  • Web-based graphical user interface
  • Isolates Video distribution network from house network
  • Works with entire IP-Logic platform
  • Provides SFP for long halls

Specification
General
ESD Protection Human body model: ±8kV (air-gap discharge), ±4kV (contact discharge)
USB 1x USB 3.0 (Reserved for future use)
Processor Marvell Armada A388 ARM A9 Dual Core 1.6GHz
Memory 1GB RAM, 8GB eMMC
SDVOE LAN Port 1x 1G RJ-45 (IP-Logic Domain), 1x 1G SFP+ Optical (AVoIP Ethernet Domain)
Control LAN Port 1x 1G RJ-45 (Facility Ethernet Domain)
Dimension 103mm x 75mm x 30mm
Temperature 0° to 40° C (10% - 90% Non-Condensing Humidity)
Power 12-VDC, 1A
Regulatory Safety and Emissions CE, FCC, RoHS
